| SPECIFICATION |
PARAMETER |
| Frequency response |
±0,5 dB 10Hz – 25kHz |
| THD+N |
<0,005%@10dB IN |
| SNR |
>105dB at 1% THD+N +22dB OUT |
| Maximum input level |
+ 24dBu / 12,28Vrms |
| Maximum output level |
+ 22dBu / 9,75Vrms |
| Gain range |
– 80dB to +12dB per channel |
| Input impedance |
> 10K Ohm . XLR enter |
| Output impedance |
< 60 Ohm . XLR output |
| Test signal |
Independent sine wave/white noise/pink noise are optional for each channel |
| Input equalization |
7-Section (parameter/high and low frame/full) |
| Extender |
Threshold/ratio/start time/recovery time adjustable |
| Qualcomm type |
Nink/Basele/Batt6/12/18/24/30/36/42/48 |
| Low pass type |
Nink/Basele/Batt6/12/18/24/30/36/42/48 |
| Adjustable delay |
200ms per channel/precision 0,01ms |
| Group delay |
2,8ms@96KHz |
| Output equalization |
Each conduction is 12 segments, supporting parameter/high and low rsck/full pass filter |
| Finite impulse response |
Low-pass/quality/bandpass direct setting, coefficients support/export |
| DRC dynamic control |
Limiting (peak or RMS value) + compression |
| Volume/mute control |
You can directly control the total volume and mute volume of the panel knob |
| Phase control |
Input/output perchannel flip 0/180 degrees |
| Online control |
USB/RS485central control online |
| Level meter |
Dynamic indication of display level |
| Power supply range |
85V-250V 50Hz-60Hz |
| Weight |
N.W 3,6kg, G.W 5,2kg |
| Outline dimension |
(46 x 482 x 250 mm), not including interface |
